Specifications:
Channels: 200
FM Storage: 20
NOAA Channels: 10
Frequency Stability: +1ppm
Size: 115mm x 60mm x 37.5mm
Weight: 234g
Voltage: 7.4V
Temperature Range: -20°C to +60°C
Resistance: 500
Transmit Power: ≤5W
Transmit Current: ≤1.5A
Sensitivity:
FM (12dB SINAD):
F1 (50-76MHz): -121dBm
F2 (108-135.9975MHz): -121dBm
F3 (136-173.9975MHz): -123dBm
F4 (174-349.9975MHz): -123dBm
F5 (349-399.9975MHz): -123dBm
F6 (400-469.9975MHz): -123dBm
F7 (470-599.9975MHz): -121dBm
WFM (76-108MHz, 20dB SINAD): -110dBm
AM (10dB S/N): -113dBm
Audio Power: ≥0.5W
Audio Distortion: ≤10%
Frequency Band: 144-148MHz/430-440MHz
Output Power: ≤5W
Output Current: ≤1.5A
Frequency Offsset: ≤5KHz (25KHz) / ≤2.5KHz (12.5KHz)
Distortion: ≤5%
Spurious: -7.5uW
Imminent Power: 70dB (25KHz) / 60dB (12.5KHz)
Residual: 40dB
